Journal Publications

1. Ankush Chattopadhyay, “Modeling of negative capacitance underlap gradedchannel junction accumulation mode junctionless FET in nano-scale regime”, Micro and Nanostructures, vol. 183, no.207756, Impact Factor: 3.1, Jan. 2024, doi:https://doi.org/10.1016/j.micrna.2024.207756 .
2. Ankush Chattopadhyay, Chayanika Bose, "” Investigation of Core-Shell  Junctionless Gate Stack DG-FET in low power application using Charge Based  Modeling”, Journal of Elec. Materi., vol. 53, pp. 157-170 (14 October 2023), Impact Factor: 2.1, doi: https://doi.org/10.1007/s11664-023-10742-x
3. Rahul Das, Ankush Chattopadhyay, Manash Chanda, Chandan K. Sarkar, Chayanika Bose, “Analytical Modeling of sensitivity parameters influenced by practically feasible arrangement of bio-molecules in Dielectric Modulated FET biosensor”, Silicon (28^thJanuary 2022), Impact Factor: 3.4, doi: https://doi.org/10.1007/s12633-021- 01617-z.
4. Ankush Chattopadhyay, Chandan K. Sarkar, Chayanika Bose, “Compact Programming language known analytical modeling of underlap gate stack graded channel junction accumulation mode junctionless FET in subthreshold regime”, Superlattices and Microstructures (28^thDecember 2021), Impact Factor: 3.22, doi: https://doi.org/10.1016/j.spmi.2021.107110.
5. M. Goswami, A. Chattopadhyay, C. Bose, “Performance Analysis of Dual Material Junction Accumulation Mode tri gate Junctionless SOI FET: Modeling and Simulation”, Silicon (27^thOctober 2021), Impact Factor: 3.4, https://doi.org/10.1007/s12633-021-01483-9.
6. A. Chattopadhyay, M. Chanda, C. Bose, C. K. Sarkar, “Analytical Modeling of Harmonic Distortions in GAA Junctionless FETs for Reliable Low-Power Applications”, Journal of Elec. Materi. vol. 50, pp. 4606-4618 (25^thMay 2021), Impact Factor: 2.1, doi: https://doi.org/10.1007/s11664-021-08999-1.
7. Ankush Chattopadhyay, Manash Chanda, Chayanika Bose, Chandan K. Sarkar, “Analytical modeling of linearity and intermodulation distortion of 3D gate all around junctionless (GAA – JL) FET”, Superlattices and Microstructures, vol. 150, (5^thJanuary 2021), Impact Factor: 3.22, doi:https://doi.org/10.1016/j.spmi.2020.106788.
8. Ankush Chattopadhyay, Chayanika Bose, Chandan K. Sarkar, “Compact Modeling of Graded N-Channel Independent Gate FET with Underlaps, Spacer and S/D Straggle for Low Power Application” Silicon, vol. 13, pp. 375–387, (13^thMarch 2020), Impact Factor: 3.4, doi: https://doi.org/10.1007/s12633-020-00424-2.
9. Ankush Chattopadhyay, Atanu Kundu, Chandan K. Sarkar, Chayanika Bose, “Two-dimensional modeling of the underlap graded-channel FinFET”, Journal of Computational Electronics, vol. 19, no. 2, pp. 688–699, (13^thFebruary 2020), Impact Factor: 2.1, doi: https://doi.org/10.1007/s10825-020-01458-w.
10. Ankush Chattopadhyay, Rahul Das, Arpan Dasgupta, Atanu Kundu, Chandan K. Sarkar, “A linearity based comparison between symmetric and asymmetric lateral diffusion for a 22 nm Underlapped DG-MOSFET”, Superlattices and Microstructures, vol. 107, pp. 69-82, (10^thApril 2017), Impact Factor: 3.22, doi:http://doi.org/10.1016/j.spmi.2017.03.056.
11. Ankush Chattopadhyay, Arpan Dasgupta, Rahul Das, Atanu Kundu, Chandan K. Sarkar, “Effect of spacer dielectric engineering on Asymmetric Source underlapped Double Gate MOSFET using Gate Stack”, Superlattices and Microstructures, vol. 101, pp. 87-95, (15^thNovember 2016), Impact Factor: 3.22, doi: http://doi.org/10.1016/j.spmi.2016.11.024.

Conference Publications

1. M. Goswami, A. Chattopadhyay and C. Bose, “Influence of High-k Oxide Thickness on Gate Stack DMG Junctionless SOI MOSFET,” 2021 Devices for Integrated Circuit (DevIC), 2021, pp. 193-197, doi: https://doi.org/10.1109/DevIC50843.2021.9455802.
2. A. Chattopadhyay, A. Pathak and P. Mukherjee, “Impact of Dopant variations on Junctionless Cylindrical Nanowire FETs,” 2020 IEEE VLSI DEVICE CIRCUIT AND SYSTEM (VLSI DCS), 2020, pp. 1-4, doi: https://doi.org/10.1109/VLSIDCS47293.2020.9179876.
3. A. Chattopadhyay, R. Das, A. Dasgupta, A. Kundu and C. K. Sarkar, “Effect of channel engineering on analog/RF performance of underlapped gatestack DGMOSFET in Sub-20nm regime,” 2017 Devices for Integrated Circuit (DevIC), 2017, pp. 299-302, doi: https://doi.org/10.1109/DEVIC.2017.8073956.
4. A. Chattopadhyay, A. Dutta, A. Kundu and C. K. Sarkar, “Influence on the analog/RF performance in graded channel Gate Stack DG-MOSFETs,” 2016 3rd International Conference on Devices, Circuits and Systems (ICDCS), 2016, pp. 167-169, doi: https://doi.org/10.1109/ICDCSyst.2016.7570653.

Book Chapter

1. Chattopadhyay A., Bose C., Chandan K.S. (2021) Performance and Circuit Analysis of Independent Gate FinFET. In: Das N.R., Sarkar S. (eds) Computers and Devices for Communication. CODEC 2019. Lecture Notes in Networks and Systems, vol 147. pp 427-433, Springer, Singapore. https://doi.org/10.1007/978- 981-15-8366-7_63.
